New-Tech™ Spot Exhauster Pictures (8 of 10)
Previous PictureBack to Spot ExhaustersNext Picture
New-Tech Spot Exhauster Picture #
  • Spot Exhauster Picture SSE-8    (13-113)
  • Front View of a Custom Pinpoint Horseshoe Snorkel Exhauster.
  • This pinpoint snorkel exhauster consists of a stainless steel horseshoe vent (with a perforated face), an aluminum mounting plate and swing arm, plastic adjustment knobs and a section of smooth bore reinforced flexible hose secured to the horseshoe vent with stainless steel hose clamps.
  • This pinpoint snorkel exhauster was custom designed to fit around a funnel that was placed into a 55 gallon drum.  The users were disposing of left over test samples, pouring the samples into the funnel and then draining into the drum.  The horseshoe vent captures the fumes and odors from the samples.
